CH 87

Powerful Features


ISI Approved Engine

Overhead valve (OHV) design, lower operating temperature, high reliability and durability. Easy start: Recoil starter with auto decompress feature enables easy start Low vibration: Balanced design with low center of gravity ensures smooth running of the engine. Oil Alert which stops at low oil level gives more protection to engine Metal cam and forged crankshaft makes engine more durable. Easy maintenance and perfect compatibility for a wide range of applications.



Category:
  • All Categories
  • People

Specifications

Type

Single Cylinder,4-stroke, OHV 25 inclined Gasoline engine

Max Torque

4.5Nm @ 3600 RPM

Rated Speed

3600 RPM

Displacement

87 CC

Oil Capacity

0.35 litres

Ignition System

Transistorized magneto

Starting System

Recoil Start

Air Cleaner

Dry, dual element type

Fuel Consumption

< 420g / kWh

Width

260 mm

Max Power

2.4hp @ 3600 RPM

Rated Power

2.1hp @ 3600rpm

Borex Stroke (mm)

54 mm x 38 mm

Compression Ratio

8.0:01

Lubrication System

Splash Lubrication

P.T.O.Shaft Rotation

Anti-clockwise

Fuel Tank Capacity

1.5 litres

Length

310 mm

Height

305 mm

CHD 87 Design and Power Curve

*Product specifications subject to changes without prior notification.
